Live Tank Circuit Breaker
Since the test voltage for the Main Contacts is between 7.5 V and 15 V, it
is important to provide good connections between the Contact
Monitoring cables and the bushings. To relieve the clips of cable weight
and ensure better contact especially in windy conditions, wrap the
cables around the porcelain.
Measuring motion may be difficult for most live tank circuit breakers due
to the inaccessibility of the moving components.
Table 4.3 lists the circuit breaker adapters available.
Table 4.3 Circuit Breaker Adapters
Doble
Adapter
Circuit Breaker
Manufacturer
Circuit Breaker Type
TR3172 Westinghouse SFA
TR3173 GE GE Metalclad Air Magnetic Circuit
Breakers (specify 13.8 or 4 kV)
TR3174 GE GE Metalclad Air Magnetic Circuit
Breakers (above 2000 A)
TR3175 Hitachi Independent Pole Operation (IPO)
TR3176 Hitachi HVB, Ganged operating mechanism
TR3177 N/A General Purpose Tank Adapter
TR3178 Hitachi HVB-IPO Spacer
TR3179 GE Metalclad VB-1 Vacuum Circuit
Breakers
TR3180 ABB HPL Insulator Column
TR3181 ABB HPL Mechanism Cabinet
TR3182 GEC Alsthom HFG SF6
TR3183 ABB Coupling 8mmINT x 0.38 lg.
TR3184 Westinghouse SF Mechanical Interface
TR3185 N/A Universal Mechanical Transducer
Mounting
