TDR9000

™

Circuit Breaker Test System User’s Guide

72A-1898 Rev. A 11/01 4-63

Monday, November 26, 2001 1:09 pm

OTE

When a test with a length greater than 5 minutes is completed, the

Safety Bypass Plug must be used. The TDR9000 will not commence a

test without it.

K A Signal Viewer functionality button that is used to

restore both the Trip Command or Close Command

graph once they have been closed. Right-click

anywhere on the Parameters window to access

Signal Viewer help or the Signal Viewing

Properties window.

Table 4.6 Recording Lengths and Sampling Rate

Recording Length Sampling Rate

500 ms 10 kHz

1600 ms 10 kHz

10 s 1 kHz

30 s 500 Hz

1 min 200 Hz

5 min 50 Hz

20 min 10 Hz
