TDR9000

™

Circuit Breaker Test System User’s Guide

72A-1898 Rev. A 11/01 B-31

Monday, November 26, 2001 1:09 pm

Table B.5 Cable Replacement List

Part Number Description

02C-0019-01 Chassis Ground cable (30 feet)

071-0021-01 External Cable kit

02B-0050-10 Safety Switch cable (25 feet)

181-0095 Power cord (USA standard)

401-0168 RS-232 cable (25 feet)

05B-0620-01 OCB cable (60 feet, standard)

020-0127-01 through 04 EHV cable set (Specify module number)

05B-0621 EHV cable, individual

(specify module number and phase)

05B-0634-01 through 03 Analog channel cable

(specify red, yellow or blue)

05B-0635-01 through 03 Auxiliary channel cable

(specify red, yellow or blue)

02B-0013-06 Trip/Close Control cable

05C-0648-01 Safety Plug w/Flag

(used for External Trigger test)

181-0107 Motion Transducer cable (40 feet)

03C-1397-01 Battery Clips (black)

03C-1398-01 Battery Clips (red)
