TDR9000
™
Circuit Breaker Test System User’s Guide
72A-1898 Rev. A 11/01 3-5
Monday, November 26, 2001 1:09 pm
Basic Virtual Front Panel Functionality
The Virtual Front Panel provides general functionality used to operate the
Instrument and to interpret the tests being configured or run. This section
covers:
• Navigating the TDR9000 Virtual Front Panel tab in TRXField
• Module level vs. connector level configuration
• Understanding connector indications
• TDR9000 Physical and Virtual Front Panel Numbering
Tab Navigation
Figure 3.3 and Figure 3.4 show the tabs that comprise TRXField
operations. By navigating these tabs, data is entered, edited or viewed.
Figure 3.3 shows the tabs that appear when beginning a new Test Plan.
Figure 3.4 shows the tabs that appear when an existing Test Result is
opened or after a test is run. A description of each tab follows.
Figure 3.3 Navigating Tabs I
Figure 3.4 Navigating Tabs II
