TDR9000
™
Circuit Breaker Test System User’s Guide
72A-1898 Rev. A 11/01 G-7
Monday, November 26, 2001 1:09 pm
Test Exceptions Procedure
Use the following steps to resolve the error messages indicated in
Table G.5.
1. Ensure that the equipment under test does not exceed TDR9000
operating limits.
2. Perform the Trip/Close test given in ”Trip/Close Function Test”
on page C-13.
3. Call customer service.
There must be an external trigger
plug connected in order to run an
externally triggered test. Remove
the safety switch and insert the
external trigger plug.
N/A
There must be a safety switch
connected in order to control the
breaker under test. Remove the
external trigger plug and connect
the safety switch.
N/A
Safety switch already pressed
before start of test.
Run test again, pressing safety
switch only when tone is heard.
Trigger input already in active
state.
Change the trigger setting or add
another trigger.
Table G.5 Test Exceptions (Continued)
Error Message Solution
