72A-1898 Rev. A 11/01 H-1

Monday, November 26, 2001 1:09 pm

Appendix H. TDR9000

™

Circuit Breaker Test

System Specifications

This appendix details specifications for the TDR9000 and its operations

in the following areas:

• OCB/Motion module

• EHV module

• Event module

• System module

• Physical

• Environmental

OCB/Motion

Table H.1 lists the characteristics of the OCB/Motion module.

Table H.1 OCB/Motion Module

Characteristic Description

OCB

Main Contact Channels 3 channels with 1 break per phase

Contact Sense Voltage for

Main Contact Timing

48/15/7.5 VDC

(Modified by pre-insertion resistor value)

Contact Sense Voltage for

Resistor Switch Timing

48/15/7.5 VDC

(Modified by pre-insertion resistor value)

Close and Open Timing

Resolution

100 microseconds

Close and Open Timing

Accuracy

100 microseconds

Minimum Contact Bounce

Measurement

60 microseconds

Pre-Insertion Resistor

Value Range

10 - 400 Ohms or 300 - 7000 Ohms
