doble TDR9000 - EHV Module; Table H.2 EHV Module

To Next Page

To Previous Page

TDR9000

™

Circuit Breaker Test System User’s Guide

72A-1898 Rev. A 11/01 H-3

Monday, November 26, 2001 1:09 pm

EHV Module

Table H.2 lists the characteristics of the EHV module.

Table H.2 EHV Module

Characteristic Description

Main Contact Channels 6 channels with 2 breaks per phase

Contact Sense Voltage for

Main Contact Timing

15/7.5 VDC

(Modified by pre-insertion resistor value)

Contact Sense Voltage for

Resistor Switch Timing

15/7.5 VDC

(Modified by pre-insertion resistor value)

Close and Open Timing

Resolution

100 microseconds

Close and Open Timing

Accuracy

100 microseconds

Minimum Contact Bounce

Measurement

60 microseconds

Pre-Insertion Resistor

Value Range

10 - 300 Ohms or 200 - 500 Ohms

Resistor Value

Measurement Accuracy

10%

Capacitance Measurement

Range and Accuracy

75 to 10,000 pF in the range of
