TDR9000
™
Circuit Breaker Test System User’s Guide
72A-1898 Rev. A 11/01 2-11
Monday, November 26, 2001 1:09 pm
TDR9000
™
Physical Front Panel Configurations Supported
Table 2.1 lists the configurations possible for the Physical Front Panel.
Some configurations require that different boards be used in the
backplane slots.
Table 2.1 Physical Front Panel Configurations
Location 1 Location 2 Location 3 Location 4 Location 5 Location 6
Motion/OCB or Empty Empty Empty Empty Empty System
Motion/OCB or Empty EHV 1-2 Empty Empty Empty System
Motion/OCB or Empty EHV 1-2 EHV 3-4 Empty Empty System
Motion/OCB or Empty EHV 1-2 EHV 3-4 EHV 5-6 Empty System
Motion/OCB or Empty EHV 1-2 EHV 3-4 EHV 5-6 EHV 7-8 System
Motion/OCB or Event EHV 1-2 EHV 3-4 EHV 5-6 EHV 7-8 System
Motion/OCB or Empty Empty Empty Empty Event 5 System
Motion/OCB or Empty Empty Empty Event 4-6 Event 5 System
Motion/OCB or Empty EHV 1-2 Empty Event 4 Event 5 System
Motion/OCB or Empty EHV 1-2 Empty Empty Event 5 System
Motion/OCB or Empty EHV 1-2 EHV 3-4 Event 4 Event 5 System
Motion/OCB or Empty EHV 1-2 EHV 3-4 EHV 5-6 Event 5 System
