doble TDR9000 - Table 1.1 OCB Dead Tank Connections; Table 1.2 EHV Dead Tank Connections

TDR9000
™
Circuit Breaker Test System User’s Guide
72A-1898 Rev. A 11/01 1-3
Monday, November 26, 2001 1:09 pm
Table 1.1 OCB Dead Tank Connections
Alligator Clip Color Phase Bushing
Red A 1
Yellow B 3
Blue C 5
Black COM 2, 4, 6
Table 1.2 EHV Dead Tank Connections
Alligator Clip Color Phase Contact
Yellow Red 1
Red Red 2
Black Red COM
Yellow Red 3
Red Red 4
Black Red COM
Yellow Yellow 1
Red Yellow 2
Black Yellow COM
Yellow Yellow 3
Red Yellow 4
Black Yellow COM
Yellow Blue 1
Red Blue 2
Black Blue COM
Yellow Blue 1
Red Blue 2
Black Blue COM
