Externally, the Instrument comes equipped with an LED on the System

module Physical Front Panel that indicates proper operation of the power

supply, as shown in Figure B.14.

Figure B.14 DC Power Supply LED

If this LED is not lit when power is applied, use the Troubleshooting flow

charts shown in Figure B.9 on page B-11 and Figure B.10 on page B-12

to resolve the problem.

LED
