TDR9000

™

Circuit Breaker Test System User’s Guide

72A-1898 Rev. A 11/01 H-7

Monday, November 26, 2001 1:09 pm

Physical Specifications

Table H.7 lists TDR9000 physical specifications.

Table H.7 TDR9000

™

Physical

Characteristic Description

Enclosure High impact, molded, flame retardant

ABS.

Meets National Safe Transit Association

testing specification No. 1A for immunity

to severe shock and vibration.

Dimensions 10.0" H x 16.0" W x 15.5" D

(25.4cm x 40.6cm x 39.4cm)

Maximum Weight 30 lbs.(13.6 kg) - includes cover, printer

and maximum configuration

Supply Voltage 100 - 240 VAC 50/60 Hz

Electrostatic Discharge

Immunity

Meets IEC 1000-4-2 Level 4

(formerly IEC 801-2)

Surge Withstand

Capability

Meets ANSI C37.90 1989 ESD
