TDR9000
™
Circuit Breaker Test System User’s Guide
72A-1898 Rev. A 11/01 G-3
Monday, November 26, 2001 1:09 pm
Run Test Conflicts
Table G.3 lists the messages that appear once the Run Test button is
clicked.
Table G.3 Run Test Conflicts
Error Message
No channels have been activated. Please activate appropriate
channels.
The loaded test plan uses channels that are not available to the
connected TDR9000. Verify channel activation.
Both OCB and EHV channels have been activated. The TDR9000
cannot use both EHV and OCB at the same time. Please deactivate the
inappropriate channels and retry.
Both OCB and EHV channels have cables plugged in. The TDR9000
cannot use both EHV and OCB at the same time. Please unplug
inappropriate cables and retry.
Refer to ”Disconnecting After the Test” on page 4-100 for instructions
on how to disconnect a cable.
There must be a safety switch connected in order to control the circuit
breaker under test.
Analog channel %d is set to a current probe range, but the current
probe has not been zeroed. Proceed to current probe zeroing.
Zero probe using instructions given in ”Current Probes” on page 4-34.
EHV channel %d has been activated, but there is no cable plugged in.
Verify channel activation and connect appropriate cables.
Refer to ”Setup and Operation” on page 4-1 before proceeding.
OCB channels have been activated, but there is no cable plugged in.
Verify channel activation and connect appropriate cables.
Refer to ”Setup and Operation” on page 4-1 before proceeding.
Motion channel %d has been activated, but there is no cable plugged
in. Plug in appropriate cable into active channel.
Refer to ”Setup and Operation” on page 4-1 before proceeding.
There must be either an external trigger plug or a safety switch
connected in order to run an externally triggered test.
