TDR9000

™

Circuit Breaker Test System User’s Guide

72A-1898 Rev. A 11/01 A-55

Monday, November 26, 2001 1:09 pm

Digital

Discriminator

For more information on the Digital Discriminator, see ”Understanding

Contact Measurement” on page A-22.

Test Duration

Parameters

The Instrument supports a recording length field where a recording

length is selected from a picklist. Each recording length has a sampling

rate associated with it. When a length is selected, the sampling rate

appears below it. Table A.2 lists the Recording Lengths and their

associated sampling rate.

The user-preferred recording length can be set using the TRX Options

window.

OTE

The Test Duration parameter is not available for the Capacitance test.

Table A.2 Recording Lengths and Sampling Rate

Recording Length Sampling Rate

500 ms 10 kHz

1600 ms 10 kHz

10 s 1 kHz

30 s 500 Hz

1 min 200 Hz

5 min 50 Hz

20 min 10 Hz (Analog only)
