Table G.2 Test Plan and Instrument Configuration Conflicts –
TDR9000
™
Connected
Error Message
Motion channels are active in the test plan, but the TDR9000 does not
have a motion module. Please deactivate all motion channels.
OCB channels are active in the test plan, but the TDR9000 does not
have a OCB module. Please deactivate all OCB channels.
Channels for EHV module %d are active in the test plan, but the
TDR9000 does not have required EHV module. Please deactivate all
channels on EHV module %d.
Motion channel %d is active in the test plan, but the TDR9000 does
not have the 6 channel motion module required. Please deactivate
motion channel %d.
More than %d analog channels are active in the test plan, but the
TDR9000 does not have a fourth event module. Please deactivate all
analog channels on the fourth event module.
Analog channels are active in the test plan, but the TDR9000 does not
have any event modules. Please deactivate all analog channels.
More than %d auxiliary contact channels are active in the test plan,
but the TDR9000 does not have a fourth event module. Please
deactivate all auxiliary channels on the fourth event module.
Auxiliary contact channels are active in the test plan, but the TDR9000
does not have any event modules. Please deactivate all auxiliary
channels.
There are EHV capacitance channels active, but the TDR9000 does
not have the capacitor measurement option. Activated capacitor
channels will be ignored.
