H-2 72A-1898 Rev. A 11/01

Monday, November 26, 2001 1:09 pm

Resistor Value

Measurement Accuracy

10%

Motion Transducers

Linear Transducer

Range 0.0 - 40.0"

Resolution 0.00125"

Accuracy ± 0.1% of measured value

± 0.1" max error

Display Resolution 0.002"

Velocity 50 ft/sec max

Acceleration 1200g for 50

sec max

Rotary Transducer

Range 0 - 2880°

Resolution 0.09°

Display Resolution 0.1°

Accuracy ± 0.1% of measured value

± 0.1° max error

Velocity 120 rev/sec max

Acceleration 30 x 106 deg/sec

max

Table H.1 OCB/Motion Module (Continued)

Characteristic Description
