The TDR9000, in conjunction with the TRXField software, offers flexible
testing capabilities through a combination of TDR9000 tab access to test
command parameters coupled with Test Plan tab access to all circuit
breaker specifications used for comparative purposes. The configuration
of these parameters, and the operation of the test from the same interface,
makes the performance of multiple tests under varying test conditions
easy.
After the test is complete, the results can be viewed in the field using the
Tabulation and Graphics tabs. The TRXField software, which operates
the TDR9000, has the ability to overlay the results from different tests for
comparison. The TDR9000 compares Test Results against circuit breaker
specifications and presents a Pass or Fail determination on the
Tabulation tab for each measurement for which a comparative value is
set in the Test Plan. The data accumulated in the field can be transferred
to a computer running the TRX software, which stores the Test Results in
a database format for record keeping and test interpretation.
WARNING To avoid operating conditions hazardous to personnel, or harmful to the
TDR9000, carefully follow all procedures, paying specific attention to
Notes and Warnings.
Figure 2.2 shows the topology of the TDR9000 in the test environment.
