ETAS ES800 System | User Guide
ES891.x ECU and Bus Interface Module
ES892.x ECU and Bus Interface Module
Operating voltage ES891.1: 6V to 32V DC
ES891.2: 7V to 29V DC
Operating voltage (typ.) 12 V DC
Current consumption, operation Max. 7 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 4 A at 32 V DC
Current consumption, standby Typ. 17 mA at 12 V DC
Max. 25 mA
Output current per "GE" connec-
tion
Nom. max. 0.5 A
Output current per "FE" connec-
tion
Nom. max. 2 A
Energy management On/Off with start/stop of Ethernet traffic
(On/Off upstream module)
Protection Protection against reverse polarity, overload
protection
Overvoltage category
(mains supply, IEC 60664-1)
II
Operating voltage ES892.1: 6V to 32V DC
ES892.2: 7V to 29V DC
Operating voltage (typ.) 12 V DC
Current consumption, operation Max. 7 A at 6 V DC,
Max. 5 A at 12 V DC,
Max. 4 A at 32 V DC
Current consumption, standby Typ. 17 mA at 12 V DC
Max. 25 mA
Output current per "GE" connec-
tion
Nom. max. 0.5 A
Output current per "FE" connec-
tion
Nom. max. 2 A
Energy management On/Off with start/stop of Ethernet traffic
(On/Off upstream module)
Protection Protection against reverse polarity, overload
protection
Overvoltage category
(mains supply, IEC 60664-1)
II
