ETAS ES800 System | User Guide
Latency Period
Duration of the signal
All signals must have a static state for more than 20ms to be recognized reliably.
Protection
All inputs and outputs at the "I/O" connection are protected up to +/- 32 V against
surge voltages.
"I/O" Connection: Socket and matching Plug
A 25-pin Micro DSUB socket (MOLEX Micro D) is installed at the "I/O" connection.
Matching plugs for the "I/O" connection:
- Micro D Receptacle Kit (without contacts) Molex 83424-9014
- Contacts Molex 83000-0083
Optional:
- Pigtail cable Molex 83424-9021
Latency period Maximum Typical
All pins/ signals at "I/O" connection 100 ms <10 ms
NOTE
The "I/O" connection is not electrically isolated from the ground of the module's
supply voltage. Never, therefore, connect the connections marked with GND/
ground to the vehicle ground, the vehicle body or other potentials.
