44 | ES820.1 Drive Recorder
ETAS ES800 System | User Guide
"Shutdown" Events (change from "Active on" to "Passive on")
"Shutdown" Events (change from "Active on" to "Low power
standby")
"Shutdown" Events (change from "Active on" to "Fast boot
standby")
Event Abbrevia
-
tion
Description
No. in
Fig. 5-5
6 PBP Pressing the "Power" button on the module and communi-
cation at the "ETH" interface (PC or measuring module)
7 On pin Pressing the external remote "Power" button or trigger
event at the digital input ("PSCI" pin, "I/O" connection),
High to Low and communication at the "ETH" interface (PC
or measuring module)
9 On time End at a specific point in time (configurable timer) and
communication at the "ETH" interface (PC or measuring
module)
Event Abbrevia-
tion
Description
No. in
Fig. 5-5
6* PBP Pressing the "Power" button on the module and no com-
munication at the "ETH" interface (PC or measuring mod-
ule)
7* On pin Pressing the external remote "Power" button or trigger
event at the digital input ("PSCI" pin, "I/O" connection),
High to Low and no communication at the "ETH" interface
(PC or measuring module)
9* On time End at a specific point in time (configurable timer) and no
communication at the "ETH" interface (PC or measuring
module)
Event Abbrevia-
tion
Description
No. in
Fig. 5-5
7* On pin Pressing the external remote "Power" button or trigger
event at the digital input ("PSCI" pin, "I/O" connection),
High to Low and no communication at the "ETH" interface
(PC or measuring module)
9* On time End at a specific point in time (configurable timer) and no
communication at the "ETH" interface (PC or measuring
module)
