·156·
Operating manual
CNC 8055
CNC 8055i
8.
UTILITIES
·T· MODEL
SOFT: V02.2X
Accessing the programs using the explorer
Operations on sets
The user may select a set of programs that are located in the right panel of the screen. This selection
may be done either individually or by range or as a whole.
These types of selection may be carried out after pressing the <Select> softkey and any of the
options shown depending on the task to be carried out. The available options are:
• All / Nothing [ * ]
• From / To [ _ ]
• Select [ + ]
• Deselect [ - ]
•Invert
After selecting the programs individually, by range or as a whole, it is possible to carry out on them
the operations mentioned earlier.
Handling the directories
When the cursor is located on any of the "hard disk" or "remote hard disk" units of the left panel,
any of the following actions may be carried out on any of them:
• Create a subdirectory
• Rename a subdirectory
• Delete a subdirectory
Quick access to directories
Selecting a directory in the left panel and pressing the <Options> softkey, <Save position [M]>, the
explorer will remember this directory.
After selecting this option and having moved the cursor to another directory, pressing the <Options
softkey>, <Go to position [G]> option, the cursor of the explorer will automatically position in the
saved directory. Pressing the same softkey again, the explorer will return to the starting position.
Quick access keys (hot keys)
Some options of the softkeys have a hot key. A hot key carries out the same function as the option
itself. When displaying the menu of each softkey, it shows the hot key (between square brackets)
equivalent to the option.
Not all the options of the softkeys have an associated hot key.
Some operations may not be applicable to certain programs of the selection. In those cases, the user
will be informed and will be allowed to either resume or cancel the operation.
To delete a subdirectory, it must be empty.
