Operating manual
CNC 8055
CNC 8055i
STATUS
9.
·T· MODEL
SOFT: V02.2X
·163·
DNC
Diagnosis of the Ethernet connection
The screen for Ethernet status shows the following information.
• The top of the screen shows the network configuration (MAC or Ethernet address, IP address,
network mask and the IP address of the gateway).
When detecting an error in the configuration, it will show the corresponding error message.
• The mid area of the screen shows the information on data transmission and reception. With a
green background the fields that must be 0 when working fine.
• The bottom of the screen shows the data of the active services.
For the remote hard disk, it shows the IP address and the shared directory. If there is no remote
hard disk or there is an error, it shows the corresponding error message.
