Operating manual
CNC 8055
CNC 8055i
PLC
10.
·T· MODEL
SOFT: V02.2X
·177·
Monitoring
Activate / deactivate symbols
With this option it is possible to display in all available windows the symbols or mnemonics
associated to the various resources.
The names of the resources may be displayed in two ways: using their generic names (I, O, M, T,
C , R) by deactivating symbols or using their associated symbols by activating them.
When a resource has no mnemonic associated to it, it will always be displayed with its generic name.
This softkey will toggle between ACTIVATE SYMBOL and DEACTIVATE SYMBOL every time is
pressed in order to show which option is available.
Logic analyzer
It is especially suited to help in the machine start-up and for troubleshooting errors and critical
situations in signal behavior.
It is described in full detail later in this chapter.
PLC start-up
When selecting this option, the CNC will start executing the PLC program from the beginning,
including the CY1 cycle.
The CNC does not execute this option when the PLC program is running.
First cycle
When selecting this option, the CNC will execute only the initial cycle of the PLC program (CY1).
The CNC does not execute this option when the PLC program is running.
Single cycle
When selecting this option, the CNC will execute the main cycle of the PLC program (PRG) only
once.
The CNC does not execute this option when the PLC program is running.
STOP PLC
This softkey interrupts the execution of the PLC program.
Continue
This softkey resumes the execution of the PLC program.
Contacts
This option may be used to monitor the PLC program in ladder diagram.
