Fagor CNC 8055 T User Manual

Operating manual
CNC 8055
CNC 8055i
DIAGNOSIS
13.
·T· MODEL
SOFT: V02.2X
·237·
Adjustments
"Parameters" softkey
To assign new values to the machine parameters of the CNC and drive that have been defined in
the "Configuration-Parameters" screen.
The machine parameters of the axis or the spindle are updated according to the criteria defined in
the previous tables, the rest of the parameters are updated according to the general criteria:
// It is necessary to press the keystroke sequence: [SHIFT] + [RESET] or turn the CNC off
and back on.
/ Just press [RESET].
The rest of the parameters (those unmarked) will be updated automatically, only by
changing them.
If the password to the machine parameters has been defined (SETUPPSW), it will be requested
when modifying a parameter for the first time. If entered correctly, it is stored in memory and it is
not requested again unless the CNC is turned off. If the password is wrong, the parameter cannot
be modified and it will be requested again the next time.
When a parameter is changed, the CNC machine parameter table and the drive's work parameters
are updated. The [Save Parameters] softkey is also activated on the "Configuration - Parameters"
screen.
We suggest to access that screen and press the [Save Parameters] softkey to save the parameter
tables that have been changed, those of the CNC into the hard disk (KeyCF) and those of the drive
in its FLASH. If only the CNC parameters have been changed, the drive tables remain unchanged
and vice versa.
Once the values saved are the same as the ones edited last, the softkey disappears until a new
modification is made.
"Actions" softkey
It is available on the following screens: "Parameter Editing", "Analysis" and "Scales /Offsets".
It is very useful when not having an alpha-numeric keyboard because it shows several softkeys to
change the data of each field (amplitude of the signals, vertical movement, time base, position of
the cursors, etc.)
"Start" softkey
It is available on the following screens: "Parameter Editing", "Analysis" and "Scales /Offsets".
It captures data according to the conditions set on the "Configuration" screen and enables the
following softkeys:
[Stop] Interrupts the capture and shows the data collected until then.
[Stop continuous] Available when the capture is continuous. It interrupts the capture and
shows the last full trace.
Once data capture has ended, or has been interrupted, it is possible to analyze the signals and
modify the parameters that have been previously selected, in order to improve the machining
conditions.
Repeat the capture, the analysis and the modification of parameters until obtaining the best
machining conditions.
