·236·
Operating manual
CNC 8055
CNC 8055i
13.
DIAGNOSIS
·T· MODEL
SOFT: V02.2X
Adjustments
"Analysis" softkey
To analyze, using 2 cursors, each signal of the last data capture.
The right side of the screen shows:
• Next to each variable, the value (V1 and V2) of the signal in the position of each cursor and the
difference between them (Dv).
• The position, in milliseconds, of each cursor (C1 and C2) and the time difference between them
(Dt).
To select the first or second cursor, use the [] [] keys to place the focus in the "C1" or "C2" fields
respectively. Then use the [] [] keys or [page up] [page down] to move the signal or press one
of these keys:
[F] To show the beginning of the trace (First)
[T] To show the trigger zone.
[S] To show the final portion of the trace (second)
[X] For the CNC to scale it automatically.
To select another portion of the sample use the [] [] keys to place the focus in the "Win" field.
Then use the [] [] keys or [page up] [page down] to move the signal or press one of these keys:
[F] To show the beginning of the trace (First)
[T] To show the trigger zone.
[S] To show the final portion of the trace (second)
[X] For the CNC to scale it automatically.
Holding the [] []keys pressed accelerates the movement.
Save/restore a trace of the oscilloscope:
The softkeys [SAVE TRACE] and [RECOVER TRACE] may be used to analyze the data of a trace
of the oscilloscope captured earlier, be it from the same CNC or from another one.
SAVE TRACE: It saves the data of a trace in the file "oscillo_trace". Saves the
configuration and the data for each channel and variable.
RESTORE TRACE: It restores the data of a trace that was saved earlier in the file
"oscillo_trace". It restores the configuration and the data for each
channel and variable.
The file "oscillo_trace" may be sent or received via WinDNC like a regular part-program.
