164
TRSTYPE DSK1-MIX
TRSTYPE DSK2-MIX
TRSTYPE DSK3-MIX
TRSTYPE DSK4-MIX
Outputs pulse while the DSK transition type is set to MIX.
TRSTYPE MEBK-WIPE Outputs pulse while the BKGD transition type is set to WIPE.
TRSTYPE KEY1-WIPE
TRSTYPE KEY2-WIPE
Outputs pulse while the KEY transition type is set to WIPE.
23-2. Tally Output
Tally information can be output from the GPI /TALLY OUT connectors on the HVS-350HS rear
and HVS-35OU/35ROU rear. See section 23-2-2. "Tally Output Settings (GPI /TALLY OUT)" for
details on settings.
Tally outputs can be expanded by installing HVS-30TALR cards (optional). See section 23-2-3.
"Tally Output Settings (HVS-30TALR).
Tally information can also be output via the Tally Unit (the Hanabi series option), in which case
the RS-422 connector is used for connection to tally units. See section 23-2-4 "Sending Tally
Signals to Tally Units."
23-2-1. Tally Color Setting
(1) Display the [SETUP- GPI/TLY -TALLY COLOR] menu.
(2) Turn F1 to select M/E PGM, then turn F2 to select the tally color for PGM. Set the tally
color for M/E PST, P/P PGM, P/P PST and AUX buses in the same way.
GPI/TLY :SELECT : COLOR : : 1/1
TLY COL : =MEPGM: =RED : :
The Tally Color settings made in this menu are shared with those for the GPI/TALLY OUT
connectors, TALLY OUT connector (HVS-30TALR) and Tally Units.
23-2-2. Tally Output Settings (GPI/TALLY OUT)
Pin assignments for the GPI/TALLY OUT Connectors are performed as shown below. See
sections 2-4-4 and 2-4-5 for the default pin assignments.
(1) Set tally colors for output buses in the [SETUP- EXT I/F-TALLY COLOR] menu.(See
section 23-2-1 "Tally Color Setting".)
(2) Select GPI OUT in the [SETUP-GPI/TLY] menu, and then press F1 or page down to
display the [SETUP - GPI/TLY - GPI OUT] menu.
(3) Turn F2 to select the pin number under P NO.
(4) Turn F3 to select a tally to be assigned under FUNCTION. (See the table "TALLY
function" below.)
(5) Set Enable to ON to enable all tally outputs of the GPI /TALLY OUT connector.
GPI/TLY : :P NO : FUNCTION : 1/1
GPI OUT : : =1 : =Out:RED TALLY-IN01
