Be careful not to use the same ARCNET ID for two different units. If an ARCNET ID conflict
has occurred and network communication fails, turn the unit power OFF at one of the
conflicting units and disconnect it from the network. Power on the conflicting unit and change
the ID to a valid network ID. Note that the new ID will not be valid until units are powered ON
again.
Before loading system data from an installed memory card, verify that the ARCNET ID
numbers that are currently assigned to the OU and MU for operation are the same as
those in the data being loaded. If a conflicting ARCNET ID (one assigned to another
OU or MU in the network) is applied by loading the system data, network operation will
fail after loading is complete.
29-2. Ethernet
The Ethernet connection is used for connecting HVS-35GUI, the control software connection or
transferring image data. (See section 29-3. "Image Data Transfer".)
Connecting to LAN
Use the twisted pair, Category 5 (UTP) cable (straight- through type) to connect the main unit
(MU) to LAN. If connecting the MU to a PC directly, use the cross-connect type cable.
IP Address, Net mask and Default Gateway Setting
Open the [SETUP-SYSTEM-ETHERNET] menu. The default settings for IP address, Net
mask and Default Gateway are as shown below.
SYSTEM : IP ADDRESS : : 1/4
ETHERNET: =192.168.000.010 : :
SYSTEM : NET MASK : : 2/4
ETHERNET: =255.255.255.000 : :
SYSTEM : DEFAULT GATEWAY : : 3/4
ETHERNET: =192.168.000.001 :
Changing IP Address, Net mask and Default Gateway
(1) Open the IP address page (or the net mask page).
(2) Press F1.
(3) The first octet (192 in the IP address example above) will be highlighted.
(4) Turn F1 to change the number.
(5) Press F1.
(6) The second octet (168 in the IP address example above) will be highlighted.
(7) Repeat (4) and (5) to change the IP address.
(8) Reboot the main unit. (See section 22-1. "Rebooting System.")
IMPORTANT
You should consult your network administrator before connecting the HVS-350 series
to a LAN network.
MAC Address
The MAC address of the network card is displayed on PAGE4.
SYSTEM : MAC ADDRESS : : 4/4
ETHERNET: 00-00-00-00-00-00 : :
