9-3. Pattern Modify Example1 (Pattern 20)
This modification example adds a border effect to background transitions using Pattern 20.
(1) Select a desired signal on the M/E PST bus.
(2) Press BKGD in the NEXT TRANSITION block.
(3) Press WIPE in the TRNSITION TYPE block.
(4) Press PATTERN in the TRANSITION block to display the [WIPE PATTERN] menu.
(5) Turn F1 to select 20.
WIPE:BKGD :KEY1 :KEY2 : 1/1
PATT:20 :00 :00 :
(6) Press the WIPE CHANNEL button to the right of the Keypad to turn BKGD to ON.
(7) Press the MENU control button, then press the WIPE button in the Keypad to display the
[WIPE] menu.
(8) Turn F1 to select BORDER. Press F1 or the page down button.
WIPE BG :>BORDER >POS/ANGL>MULTI >SUB EFF
No.020 :>CG WIPE >INIT
(9) The [WIPE - BORDER] menu appears. Turn F1 to select the signal used for the border under
SIGNAL. Select MATT in this example. Set the border width under WIDTH and border
softness under SOFT.
WIPE BG :SIGNAL : WIDTH : SOFT : : 1/2
BORDER : =MATT : =5.0 : =2.0 : :
(10) Press the page down button to go to PAGE 2.
(11) Turn F4 to select a border color among eight standard colors. Press F4 to apply the
selected color. If you want to adjust the selected color or set the color by entering HSL values,
turn F1, F2 and F3 to adjust values or press F1, F2 and F3, enter a value in the Keypad,
and then press ENTER in the Keypad. Users can also set these three parameters in the
JOYSTICK block. (See section 4-2-4. "Changing Settings or Values Using the Joystick".)
WIPE BG : BORDER COLOR :RECALL : 2/2
BORDER :S=66.3 L=5.4 H=3.5 : >BLUE :
To Next Page
