25-2-6. Salvo Switching
Salvo switching allows the user to switch multiple crosspoints (destination/source pairs)
simultaneously using stored crosspoint data. The switcher can manage only one salvo.
 Setting Crosspoints for a Salvo
(1) Open the [SETUP-EXT I/F-ROUTER] (3/6) menu.
(2) Turn F1 to select a level.
(3) Turn F2 to select a destination channel. If a source to be paired has been set, the source
channel number is displayed.
(4) Turn F3 to select a desired source and then press F3 to save the destination / source pair
to the salvo.
(5) The source setting under SRC is applied, after the salvo settings on the router have been
changed.
EXT I/F : LEVEL : DEST : SRC : SALVO : 3/6
ROUTER : =1 : =1 : =2 : >EXEC :
(6) Repeat steps (3) and (4) to set all destination / source pairs to be saved to the salvo.
 Executing the Salvo
(1) In the [SETUP-EXT I/F-ROUTER] (3/6) menu, turn F4 to select EXEC.
(2) Turn F4 to execute the salvo.
EXT I/F : LEVEL : DEST : SRC : SALVO : 3/6
ROUTER : =1 : =1 : =2 : >EXEC :
 Displaying Crosspoints in the Salvo
(1) Open the [SETUP-EXT I/F-ROUTER] (4/6) menu.
(2) Turn F1 to select a level.
EXT I/F : LEVEL : XPT :PRESET : : 4/6
ROUTER : =1 : > : > : :
(3) Turn F3. The crosspoints stored in the salvo are displayed. To move among menu pages,
use the page up and down buttons.
ROUTER : 1-1 2-2 3-3 : : 1/XX
XPT : 4-4 5-5 6-6 : >BACK :
7-7 8-8 9-9
10-10 11-11 12-12
| | |
 Clearing the Salvo
(1) In the [SETUP-EXT I/F-ROUTER] (3/6) menu, turn F4 to select CLEAR.
(2) Press F4 to clear the salvo settings.
