33-2. Setting USER Buttons on HVS-30FP and HVS-30RU
USER Button Default Assignments in HVS-30FP
Button Default setting
USER button 1 on RU1-1, RU2-1 and HVS-30RU1/2 AUX XPT SELECT
USER button 2 on RU1-2, RU2-2 and HVS-30RU1/2 PinP XPT SELECT
Assigning Functions to USER Buttons
(1) Press the USER button above the Keyapd display on the [USER BUTTON] menu.
(2) Turn F1 to select a USER button for use.
(3) Turn F2 to select OTHER to TYPE and press F2.
(4) Turn F3 to select a function to be used and press F3. See the HVS-30FP/RU operational
manual for assignable functions.
PANEL :SELECT : TYPE : FUNC(F3) : 1/1
USER BTN: =RU1-1: =OTHER: =AUX XPT SELECT
33-3. OSD Operation
Pressing the first two menu control buttons (F1 and F2) on the HVS-30RU control panel
simultaneously shows the menu on the front panel. At the same time the OSD (On Screen
Display) will appear on the preview screen. Pressing both buttons again clears the menu from
the screen. The following explains how to display the desired menu and how to change
parameters on the menu in the OSD. See "HVS-30FP and HVS-30RU operation manual" (soon
be released) for details.
To Display a Desired Menu:
(1) Turn either of the control push-buttons to select a menu and press the button to confirm the
selection.
(2) The parameters in the menu are displayed. The name of the selected menu is displayed in
the mini-screen on the HVS-30RU panel. If the menu has submenus, go to the desired
submenu in the same way and display parameters. To go back to the main menu, select
RETURN and press the button.
To Change Parameter Setting
(1) Turn either of the control push-buttons to select a parameter and press the button to confirm
the selection.
(2) Turn the button to change the setting and press the button to confirm the change.
(3) To go back to the menu selection, turn the button to select RETURN and press the button. To
exit the menu, press both buttons.
