Appendix 3 - 16
6-2. Available Transitions
Bus PGM output Type
Transition
Rate
Setting
Fader Limit
Setting
Wipe
Direction
setting
Transition Execute
Button or Tool
BLACK M/E or P/P BLACK Available － － BLACK TRANS button
DSK M/E or P/P
CUT － － －
DSK ON AIR button
DSK AUTO button
MIX Available － － DSK AUTO button
USER
TRANS
(1)
Available － － DSK ON AIR button
KEY M/E
CUT － Available －
KEY >> CUT button
KEY ON AIR button
KEY AUTO button
MIX
Available Available －
KEY >> MIX >> AUTO button
KEY AUTO button
－ Available NOR/REV Fader lever
WIPE
Available Available NOR/REV KEY >> WIPE >> AUTO button
－ Available NOR/REV Fader lever
USER
TRANS
(1)
Available － － KEY ON AIR button
PinP M/E
CUT － － －
PinP ON AIR button
PinP AUTO button
MIX Available － － PinP AUTO button
USER
TRANS
(1)
Available － － PinP ON AIR button
BKGD M/E
CUT － Available － BKGD >> CUT button
MIX
Available Available － BKGD >> MIX >> AUTO button
－ Available NOR/REV Fader lever
WIPE
(M/E only)
Available Available NOR/REV BKGD >>WIPE >> AUTO button
－ Available NOR/REV Fader lever
BKGD P/P
CUT － Available － BKGD >> CUT button
MIX Available Available － BKGD >> AUTO button
(1) Transition type is selectable from CUT (default), SCALER, SLIDE (4 directions) and WIPE (4 directions)
6-3. Black Transitions
Pressing the BLACK TRANS button initiates a fade to (or fade from) black whichever source
(background and DSK) is currently on air (program output). The Black transitions can be
performed either on the M/E and P/P bus. The BLACK TRANS button, however, is disabled as
factory default setting.
Enabling Black Transitions
(1) Press the TRANSITION RATE button to display the [TRANS-BKGD/BLK] menu.
(2) Turn F4 to change BLACK TRANS from OFF to M/E or P/P.
TRANS : M/E : P/P : BLACK TRANS : 1/6
BKGD/BLK: =30 : =30 : =P/P : =30 :
(3) Set the transition rate, if necessary.
(4) Press BLACK TRANS button to the left of the joystick to perform the transition. Once the
button is pressed, the PGM screen will fade to black whichever source (background and
DSK) is currently on air. When the button is pressed again, the PGM screen will fade from
black to the image.
To Next Page
