8-2. Quick Reference for Available Transitions
Bus PGM Out Type Rate
Fader
Limit
Pattern
Direction
Transition Execute Button or Tool
BLACK M/E or P/P BLACK Available – – BLACK TRANS button
DSK M/E or P/P
CUT – – –
DSK ON AIR button
DSK AUTO button
MIX Available – – DSK AUTO button
USER
TRANS(1)
Available – – DSK ON AIR button
KEY M/E
CUT – Available –
KEY >> CUT button
KEY ON AIR button
KEY AUTO button
MIX
Available Available –
KEY >> MIX >> AUTO button
KEY AUTO button
-- Available NOR/REV Fader lever
WIPE
Available Available NOR/REV KEY >> WIPE> > AUTO button
– Available NOR/REV Fader lever
USER
TRANS (1)
Available – – KEY ON AIR button
PinP M/E
CUT – – –
PinP ON AIR button
PinP AUTO button
MIX Available – – PinP AUTO button
USER
TRANS (1)
Available – – PinP ON AIR button
BKGD M/E
CUT - Available - BKGD >> CUT button
MIX
Available Available – BKGD >> MIX >> AUTO button
-- Available NOR/REV Fader lever
WIPE
(M/E only)
Available Available NOR/REV BKGD >>WIPE >> AUTO button
– Available NOR/REV Fader lever
BKGD P/P
CUT – Available – BKGD >> CUT button
MIX Available Available – BKGD >> AUTO button
(1) Selectable from CUT (default), SCALER, SLIDE (4 directions) and WIPE (4 directions).
8-3. Black Transitions
Just pressing the BLACK TRANS button can perform the BLACK transitions. The BLACK
transitions can be performed either on the M/E or P/P bus, but the BLACK TRANS button is
disabled as a factory default setting.
 To Enable the Black Transitions
(1) Press the TRANSITION RATE button to display the [TRANS-BKGD/BLK] menu.
(2) Turn F3 to change the setting from OFF to M/E or P/P.
TRANS : M/E : P/P : BLACK TRANS : 1/6
BKGD/BLK: =30 : =30 : =P/P : =30 :
(3) If necessary, set the transition rate. See section 8-10-2. "Transition Rate" for details.
(4) Press the BLACK TRANS button (to the left of the joystick) to perform the transition. Pressing
the button initiates a fade to black of whichever source is currently on air (program output).
Pressing the button again starts another fade from black to the previous video.
