5-2. How to Assign Sources to Bus buttons
Primary and optional video inputs, internally generated signals (black, mattes etc) and captured
stills can be freely assigned to any M/E, P/P or KEY/AUX bus buttons using the procedure
below.
(1) Press the MENU control button and then press the SETUP button to display the SETUP
menu's top page.
(2) Turn F1 to select INPUT. Press F1 or the page down button to display the [SETUP – INPUT]
menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :
(3) Turn F1 to select ASSIGN. Press F1 or the page down button to display the [SETUP –
INPUT - ASSIGN] (1/3) menu.
INPUT :BUTTON : SIGNAL NAME :INHIBIT: 1/4
OU ASSGN: =01 : =IN04 : =IN04 : =OFF :
(4) Turn F1 to select a bus button under BUTTON.
(5) Turn F2 to select the signal to be assigned under SIGNAL. Users can also select a signal by
turning F3 under NAME. SIGNAL and NAME are linked to each other. (See section 5-1.
"How to Give Name to Source" for more details.)
Submenu Parameter Default Setting range
OU ASSIGN
BUTTON 1 1-24, sft1-sft24 (shifted buttons)
SIGNAL
NAME
IN01 (See the table below)
IN01 (Signal name set in SETUP-INPUT menu)
INHIBIT OFF OFF, M/E, P/P, ME&PP
BUTTON SIGNAL setting Description
01 to 20,
sft01 to sft20
(shifted
buttons)
NONE No signal assignment
BLACK Black signal
IN01 to IN08 Video input to rear connectors 1-8
STIL1 to STIL4 Still pictures 1 and 2
STILK Still KEYOUT
MATT1, MATT2 BUS MATT Color 1 and 2
CLBAR Internally generated color bar signal
M/E M/E program re-entry (P/P bus only)
SHIFT Shift button function
INA1-INA4 Optional video input to slot A (*1) (See section 2-3.)
INB1-INB4 Optional video input to slot B (*1) (See section 2-3.)
INC1-INC4 Optional video input to slot C (*1) (See section 2-3.)
IND1-IND4 Optional video input to slot D (*1) (See section 2-3.)
(*1) Inputs vary by the type and number of the installed input expansion card.
(6) Users can inhibit specific bus buttons. If INHIBIT is set to M/E, P/P or ME&PP, the selected
bus button on the M/E bus, P/P bus or both cannot be selected. This is useful to help reduce
the risk of incorrect input selection.
IMPORTANT
The INHIBIT setting has no effect for the KEY/AUX bus. Even if a bus button cannot be
used on the M/E and P/P, it can be used for the key source, key insert or AUX output.
