5. Video Sources
5-1. How to Give Name to Sources
Signals available for selection on the M/E, P/P and the KEY/AUX bus can be assigned
user-specific names, to make them easier to identify for operators. User names can be given to
input signals, internally generated black matt and matt signals, and still pictures. Follow the
procedure below to name a signal.
(1) Press the MENU control button above the numeric keypad and then press the SETUP button
to display the SETUP menu's top page.
(2) Turn F1 to select INPUT. Then press F1 or the page down button to display the [SETUP-
INPUT] menu.
(3) Turn F1 to select RENAME. Press F1 or the page down button to display the [SETUP-
INPUT- RENAME] menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :
(4) Turn F1 to select a signal under SELECT. (See the table below.)
INPUT :SELECT :SHORT : LONG NAME (MV) : 1/1
RENAME : =IN04 : =IN04 : =INPUT04 :
SELECT
SHORT
default setting
LONG NAME
default setting (*1)
Signal description
BLACK BLAK BLACK Black signal
IN01IN08 IN01 to IN08 INPUT01 to INPUT08 SDI video input to rear connectors 1-8
STILL1 to
STILL4
STL1 to STL4 STILL1 to STILL4 Still images 1 to 4
STILK STKY STILLKEY Still KEYOUT
MATT1 to 2 MAT1 to MAT2 MATTE1 to MATTE2 BUS matte color 1 and 2
CLBAR CLBR COLOR BAR Color bar
INA1 to INA4
INB1 to INB4
INC1 to INC4
IND1 to IND4
IN09 to IN24
(*2)
INPUT09 to INPUT24
(*2)
Optional video inputs on Slot A to D
(See section 2-3.)
(*1) Long names are used for titles displayed on the multiviewer screen.
(*2) IN05 and following inputs are determined by the type and number of the installed input expansion card.
(5) To change the short name of a signal, use F2 to give it a name up to 4 characters in length,
entering the characters one by one. First, press F2 to highlight a character. When the latter is
highlighted, turn F2 to change it. Alphabet, numbers and symbols (ASCII characters) can be
used for names.
(6) To change the long name of a signal, use F3 to give it a name up to 8 characters in length,
entering the characters one by one. First, press F3 to highlight a character. When the latter is
highlighted,, turn F3 to change it. Alphabet, numbers and symbols (ASCII characters) can be
used for names.
