Tally Control Example
The setting example in the table below shows how to make tally settings in the following
conditions. Pins1-8 send on-air tallies and Pins 9-16send Next tallies.
Conditions
RED tally is used to indicate On-Air (M/E PGM bus).
GREEN tally is used to indicate a next background signal (M/E PST bus).
Pins1-8 output RED tallies for IN01-IN08 respectively.
Pins 9-16 output GREEN tallies for IN01-IN08 respectively.
Menu Setting
Menu Items Setting Item Setting
TALLY
COLOR
SELECT M/E PGM COLOR RED
SELECT M/E PST COLOR GREEN
GPI OUT
P NO 1 to 8 FUNCTION
RED TALLY IN01 to RED TALLY IN08
(default setting)
P NO 9 to 16 FUNCTION
GREEN TALLY IN01 to GREEN TALLY
IN08
