No. Name Description Refer to
1 ALARM indicator
Indicates the fan alarm status in the main unit.
The indicator blinks red when an alarm occurs. In
such a case, power off the system and consult your
FOR-A supplier. The indicator is normally unlit.
This indicator works the same as the ALARM indicator
located on the front panel of the main unit.
2 Menu Control Block
The menu control block is composed of the menu
display, menu control push-buttons (F1 to F4) and
page up/down buttons.
4
3
SELECT/
KEYPAD
Used for menu setting, number input, pattern
selection, event control and sequence operation.
Four memory buttons (WIPE, 2D DVE, EVENT,
SEQUENCE) and four control buttons (MENU, USER
BUTTON, COPY/SWAP and SEQ EDIT) above the
keypad change the keypad mode.
4-1-1
4-2-3
8-8-2
17
18
4 BLACK TRANS Used to perform black transitions. 8-3
5 USB MEMORY
Used to connect a USB flash memory for image file
import and export or system setting backup.
(USB1.1, Type-A)
19
6 USER BUTTON
User assignable buttons. Menu shortcuts or functions
can be assigned to these buttons.
21
7 BUS SELECT Block
Used to select a bus, then to select a video in the
KEY/AUX bus (No 8).
6-1-1
10
15-1
16-1
8 KEY/AUX Bus
Used to select video for the bus selected in the BUS
SELECT block (No. 7).
The video can be selected from KEY/AUX bus
buttons, PGM, PREV, CLEAN and MV.
9 M/E Bus Used to select video for M/E background.
10 P/P Bus Used to select video for P/P background. 5
11 Joystick Block
Used to set position, size or color settings in the
specific menu parameters.
4-2-4
12 M/E Transition Block
Used to perform transitions for M/E background and
KEY.
8
13
KEY/DSK/PINP
Transition Block
Used to perform transitions for KEY, DSK and PINP. 16-2
14 P/P Transition Block Used to perform transitions for P/P background. 8
