Setting Example when using Re-entry
In the following menu settings, if the M/E bus signal is changed to IN04 on the switcher, the
audio playback is changed to No.1 on the Audio Mixer.
In addition, when the P/P bus is set to FLWME for the M/E signal as shown below, the audio
playback is set to No.1 on the Audio Mixer if the M/E re-entry signal is selected on the P/P
bus and the M/E bus signal is changed to IN04,
EXT I/F :ENABLE : BUS :SIGNAL :AUD XPT: 1/1
AUD MXR : =ON : =M/E : =IN04 : =1 :
EXT I/F :ENABLE : BUS :SIGNAL :AUD XPT: 1/1
AUD MXR : =ON : =P/P : =M/E : =FLWME:
Default Video and Audio Assignments
Video Audio bus
BLACK NONE
IN01 to IN24 1 to 24
STILL1 to 4 NONE
STILLKEY NONE
MATTE1 NONE
MATTE2 NONE
COLORBAR NONE
M/E NONE
