Appendix 3 - 21
When pressing the DIRECT PATT button, the number buttons onto which patterns are
already saved light up. If a user presses one of them to save a selected pattern, the
number button blinks. To overwrite the pattern, press the number button again. (To cancel
overwriting, press STORE.)
To Select a Pattern:
(1) Press DIRECT PATT to display the [DIRECT PATTERN] menu. The [DIRECT PATTERN]
menu is displayed and the keypad changes to DIRECT PATTERN mode.
(2) Turn F4 to select a bus where the pattern is being used.
DIRECT : PAGE :DIRECT :CLEAR :SELECT : 1/1
PATTERN : =0 : =ON : >OFF : =BKGD :
(3) Turn F1 to select a page of the Direct Pattern memory.
(4) Press the number button where the desired pattern has been saved. The button blinks.
(5) Press RECALL to recall the registered pattern.
