Each card has two output channels whose signals can be selected respectively in the menu as
shown in the procedure below.
(1) Open the [SETUP – OUTPUT – OPTION] menu.
(2) Turn F1 to select an output channel. E-Ch1 and E-Ch2 is for Slot E and F-Ch1 and F-Ch2 is
for Slot F.
(3) Turn F1 to select an image to be output from MEPGM, MEPREV, MECLN, PGM, PREV,
CLN, AUX1 to AUX8, MV1 to MV2.
OUTPUT :SELECT :OUTPUT :FORMAT :ASPECT : 1/2
OPTION : =E-Ch1: =MEPGM : =SXGA : =4:3 :
(4) Select the signal format and aspect ratio. Available selections are shown in the tables below.
If HVS-30HSDO is installed:
System format Channel FORMAT setting ASPECT setting
HD Ch1 HD-SDI (Fixed) -----
1080i/59.94, 50,
1080PsF/29.97, 25
720p/59.94, 50
Ch2
HD-SDI (Fixed) -----
SD-SDI (Fixed) 4:3, SQUEEZE, LETTER
SD Ch1, Ch2 SD-SDI (Fixed) ---
If HVS-30HSAO is installed:
System format Channel FORMAT setting ASPECT setting
HD
Ch1 HDComponent -----
Ch2
HDComponent -----
SDComponent,
Composite *
4:3, SQUEEZE,
LETTER
SD
Ch1,
Ch2
Component *
(SMPTE or BetaCam level),
Composite *
-----
* You can choose whether to add 7.5% Setup to the output signals if the switcher is running in 59.94 Hz
mode. If 7.5% Setup is added to a signal, the symbol "+" follows immediately after the name of the
signal.
If HVS-30PCO is installed:
System format Channel FORMAT setting ASPECT setting
1080i
Ch1,
Ch2
1280x1024 (SXGA), 1600x1200 (UXGA) 4:3, LETTER
1680x1050 (WSXGA), 1920x1200 (WUXGA),
1920x1080 (HDTV) *
-----
720p
Ch1,
Ch2
1280x1024 (SXGA) 4:3, LETTER
1280x768 (WXGA) -----
SD
Ch1,
Ch2
800x600 (SVGA) -----
* You can choose between 60 Hz and 50 Hz for the output frequency for DVI-D (Ch 1) if the switcher is
running in 50 Hz mode (1080/50i, 720/50p or 625/50). See step (5) below.
(5) Select the output frequency for HVS-30PCO between 60Hz and 50Hz in the [SETUP –
OUTPUT – OPTION] (2/2) menu. The setting can be made for each channel by turning menu
controls. The setting is available only when the switcher is running in 50Hz mode.
OUTPUT : HVS-30PCO V SCAN FREQUENCY : 2/2
OPTION :E1=60Hz E2(60Hz)F1=60Hz F2(60Hz):
