Installing the AC Cord Retaining Clip
1) Insert both ends of the retaining clip into the holes on the sides of the hexagon head screws.
2) Plug the AC cord securely into the AC inlet
3) Push the retaining clip into place against the AC cable.
4) Installation is complete.
Hexagon head scre
Retaining clip
AC cable
(Push the retaining clip against
the AC cable until it locks.)
