DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
4-40 Section 4-8 - Mechanical Function Checks
4-8-8 Flexible LCD Arm Function Validation Procedure
• Check if the flexible arm operates properly.(Up-down, rotation and tilting mechanism)
• Check if the flexible arm cover parts can not be removed easily.Check if the lock operates properly.
Figure 4-37 Check the Flexible LCD Arm
