GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 1-2 - Important Conventions 1-5
1-2-3 Product Icons
The following table describes the purpose and location of safety labels and other important information
provided on the equipment.
Table 1-5 Product Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION
Identification and Rating Plate
Manufacturer's name and address
Date of manufacture
Model and serial numbers
Electrical ratings
Rear of console near power inlet
Under monitor
On each probe
Device Listing/Certification Labels
Laboratory logo or labels denoting
conformance with industry safety standards
such as UL or IEC.
Rear of console
Under front of monitor
Type/Class Label
Used to indicate the degree of safety or protection.
IP Code (IPX8)
Indicates the degree of protection provided by
the enclosure per IEC 529. IPX8 indicates drip
proof.
Footswitch
Equipment Type CF (heart in the box symbol)
IEC 878-02-05 indicates equipment having a
high degree of protection suitable for direct
cardiac contact.
IEC60601-2-27
ECG connector
Surgical probes
Defibrillator
"CAUTION" The equilateral triangle is usually
used in combination with other symbols to
advise or warn the user.
Various
ATTENTION - Consult accompanying
documents " is intended to alert the user to
refer to the operator manual or other
instructions when complete information cannot
be provided on the label.
Various
"CAUTION - Dangerous voltage" (the lightning
flash with arrowhead in equilateral triangle) is
used to indicate electric shock hazards.
Various
"Mains OFF" Indicates the power off position of
the mains power switch.
Rear of system adjacent to mains switch
