DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
9-4 Section 9-3 - MONITOR
Section 9-3 MONITOR (cont’d)
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X R3.0.X~ R4.0.X~
101
LA5 monitor cover set 5144589-3 LOGIQ A5 1 1 Yes Yes Yes
LP5 Monitor cover set 5144590-3 LOGIQ P5 1 1 Yes Yes Yes
LP5 Monitor Cover Set 5252337-2 1 1 Yes
102
LCD Arm with cover 5144507 LOGIQ A5 1 1 Yes Yes Yes
LCD Flexible Arm KIT 5264538 LOGIQ P5 1 1 Yes Yes Yes
LCD Arm with cover 5399274 LOGIQ P5 1 1 Yes
LCD Flexible Arm KIT 5257303-3 Common with LP6 1 1 Yes
103
P5 LCDMON II Assy 5328696 LOGIQ P5 1 1 Yes Yes Yes
A5 LCDMON II Assy 5328697 LOGIQ A5 1 1 Yes Yes Yes
P5 BT11 LCDMONII Assy 5399193 LOGIQ P5 1 1 Yes
Table 9-2 MONITOR

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
