DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 4-9 - Board Function Checks 4-47
4-9-4 SYSCONML Assy Function Validation Procedure
4-9-4-1 L1SYSCON diagnostic Test
1.) Turn on the system and check the completion of echoloader loading.
2.) Do the Service Login. Refer to 5-10-2-2 "Service Login" on page 5-41.
3.) Select 'Diagnostics' => 'LOGIQ P5 Diagnostics' => 'FRU test' => 'L1SYSCON' => 'L1SYSCON
Overall'.
4.) Execute the diagnostic test.
5.) All diagnostic test item of L1SYSCON should be passed.
6.) Shut down the system.
7.) Restart the system
8.) Check the basic function of system's different modes. Refer to 4-3-4 "System B/M-Mode Checks"
on page 4-8 and refer to 4-3-5 "System CFM and PWD Checks" on page 4-9.
4-9-4-2 Peripheral Test
Refer to Section 4-5 "Peripheral Checks" on page 4-26.
Figure 4-46 L2SYSCON Diagnostic Test

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
