GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
5-34 Section 5-7 - Power Diagrams
5-7-4 AC Power Outlet for Peripheral
The ARP CONN ASSY and ARP CONN 220V ASSY are the ARP assemblies which interconnect
external signal and power with the LOGIQ™ P5 system. Both of the assemblies are the same except
the circuit breaker's current ratings depending on voltage of the system power source (See 'Safety'
described below).
5-7-4-1 Safety
• Circuit Breaker
• Electrical Isolation
The ARP's Insite interface is electrically isolated from the system's internal circuit. The isolator's
dielectric strength should be 500VAC RMS or higher within 1 minute (in compliance with IEC60601-1-
1).
Table 5-4 Circuit Breaker Specification
Assembly
Power Voltage
Rating (V)
Peripheral Current
Rating (A)
Trip Time Reset Time
ARP CONN
110
4.0
1 hour max. @
5.4A, 25 degreeC
110 second
ARP CONN 220V
220
2.0
1hour max. @
3.5A, 25 degreeC
180 second

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
