GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 8-2 - DISASSEMBLY/RE-ASSEMBLY 8-67
8-2-25 Dummy Cover L / R
8-2-25-1 Tools
• Common pilIips screwdrivers
8-2-25-2 Preparations
• Shut down the system and switch off the main breaker.
8-2-25-3 Removal procedure
1.) Remove 2 rubber caps (1-2).
2.) Unscrew 2 screws and remove the dummy cover L.
3.) Same process is applied for dummy cover R.
Figure 8-102 rubber cap of dummy cover
Figure 8-103 screws of dummy cover

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
