GE HEALTHCARE

DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL

9-6 Section 9-4 - KEYBOARD

Section 9-4 KEYBOARD (cont’d)

Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X R3.0.X~ R4.0.X~

200

LOGIQ P5 Main Keyboard Assy 5144536 LOGIQ P5 ONLY 1 1 Yes Yes Yes

LOGIQ A5 Main Keyboard Assy 5171625 LOGIQ A5 ONLY 1 1 Yes Yes Yes

LOGIQ P5 Main Keyboard Assy for

JPN

5334846 LOGIQ P5 Japan Only 1 1 Yes

LOGIQ A5 Main Keyboard Assy for

JPN

5334848 LOGIQ A5 Japan Only 1 1 Yes

Main Keyboard Assy 5252353 Common with LP6 1 1 Yes

Main Keyboard Assy for JPN 5334850 Common with LP6 1 1 Yes

201

LOGIQ P5 Sub Keyboard Assy 5144538-2 LOGIQ P5 ONLY 1 1 Yes Yes Yes

LOGIQ A5 Sub Keyboard Assy 5177533-2 LOGIQ A5 ONLY 1 1 Yes Yes Yes

LOGIQ P5 Sub Keyboard Assy for

JPN

5334847 LOGIQ P5 Japan Only 1 1 Yes

LOGIQ A5 Sub Keyboard Assy for

JPN

5334849 LOGIQ A5 Japan Only 1 1 Yes

LP5 Sub Keyboard Assy 5399194 LOGIQ P5 1 1 Yes

LP5 Sub Keyboard Assy for JPN 5399192 LOGIQ P5 1 1 Yes

202 Trackball Assy 5144543 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

203

English A/N Key Assy 5144533 LOGIQ P5/A5 1 1 Yes Yes Yes

Greek A/N Key Assy 5168937 LOGIQ P5/A5 1 1 Yes Yes Yes

Russian A/N Key Assy 5167845 LOGIQ P5/A5 1 1 Yes Yes Yes

Swedish A/N Key Assy 5177708 LOGIQ P5/A5 1 1 Yes Yes Yes

Norwegian A/N Key Assy 5176980 LOGIQ P5/A5 1 1 Yes Yes Yes

English A/N Key Assy 5252354 Common with LP6 1 1 Yes

Greek A/N Key Assy 5252355 Common with LP6 1 1 Yes

Russian A/N Key Assy 5252356 Common with LP6 1 1 Yes

Swedish A/N Key Assy 5252357 Common with LP6 1 1 Yes

Norwegian A/N Key Assy 5252358 Common with LP6 1 1 Yes

204 Freeze Key Assy 5144540 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

205 TGC Key Assy 5144541 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

206 TGC Knob Set 5144542 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

207 Sub Keyboard Encoder Knob set 5144539 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

208 LOGIQ P5 Keycap set 5144547 LOGIQ P5 ONLY 1 1 Yes Yes Yes Yes

209 Main Keyboard Encoder Knob set 5177823 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

210 Speaker Pad 5224928 LOGIQ P5/A5 1 1 Yes Yes Yes Yes

Table 9-3 KEYBOARD

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
