GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 7-6 - LED Descriptions 7-21
Section 7-6
LED Descriptions
7-6-1 CL1TRX/BL1TRX Assy
The CL1TRX/BL1TRX Assy is located at the No.1 slot in the NEST Assy.
7-6-2 P3RLY/P2RLY Assy
The P3RLY Assy is located at the front of the NEST Assy.
7-6-3 SYSCONPM/SYSCONCM Assy
The SYSCONPM/SYSCONCM Assy is located at the No.3 slot of the NEST Assy.
Table 7-8 LEDs on CL1TRX/BL1TRX Assy
LED
Descriptions Normal State
DS1 FPGA configuration OK status Indicator Normally Blinking
Table 7-9 LEDs on P3RLY/P2RLY Assy
LED
Descriptions Normal State
D1 MUX embedded Probe Recognition Indicator Normally On
D2 Selected probe connector position number bit 0 Depend on live probe position
D3 Selected probe connector position number bit 1 Depend on live probe position
D4 FPGA Configuration OK status indicator Normally On
Table 7-10 LEDs on L1SYSCON Assy
LED
Descriptions Normal State
DS1 CPDI FPGA configuration OK indicator Normally On
DS2 Frame Start signal. Scan running status indicator Normally blinking on scanning
DS3 FEBC FPGA configuration OK indicator Normally On
DS4 DSP operation OK indicator Normally blinking

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
