GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
7-20 Section 7-5 - Common Diagnostics
7-5-4-5 APS/APS Pro
These programs are provided for testing the APS board.
7-5-4-6 FRONT PANEL
These programs are provided for testing the Front panel.
NOTE: For the EchoBack test, it is highly recommended to press a button less than two times per a
second.
NOTE: When Abort button is pressed to finish EchoBack test, you have to wait until “Completed.”
message is displayed to proceed other tests.
Table 7-6 FRU Test, APS Diagnostics Menu
Menu
Descriptions
User
Level
Tools
Full Test
Performs all of the APS test listed below All None
HV voltage
stability
Read HV voltage and display HV values. All None
LV voltage
stability
Read HV voltage and display LV values. All None
Table 7-7 FRU Test, ACWD Diagnostics Menu
Menu
Descriptions
User
Level Tools
FRONT PANEL
Overall
Performs all of the Front Panel tests listed below All None
FRONT PANEL
Revision
Test EEPROM.Send test pattern to write to EEPROM and read.Displays the board
revision of the Front Panel.
All None
ROM
Makes a check of internal ROM check sum. All None
RAM
Writes / reads data over all address of RAM and also makes a check of control
program.
All None
EEPROM
Writes / reads data over all address of EEPROM All None
SWITCH
Test switch in Front Panel. All None
Echoback
Rotate or depress any key, Verify that it is displayed on the CRT monitor. To finish the
test, press “Abort” key and wait until complete message appears.
All None

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
