GE LOGIQ P5 Service Manual

GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 4-3 - General Procedure 4-13
4-3-8 Using Cine
4-3-8-1 Activating CINE
Press FREEZE, then roll the TRACKBALL to activate CINE. To start CINE Loop playback, press Run/
Stop. To stop CINE Loop playback. press Run/Stop.
4-3-8-2 Quickly Move to Start/End Frame
Press FIRST to move to the first CINE frame; press LAST to move to the last CINE frame.
4-3-8-3 Start Frame/End Frame
Turn the START FRAME dial to the left to move to the beginning of the CINE Loop. Turn the dial to the
right to move forward through the CINE Loop.
Turn the
END FRAME dial to the right to move to the end of the CINE Loop. Turn the dial to the left to
move backward through the CINE Loop.
4-3-8-4 Adjusting the CINE Loop Playback Speed
Turn the LOOP SPEED dial right/left to increase/decrease the CINE Loop playback speed.
4-3-8-5 Disconnecting B-Mode CINE from Timeline CINE
To review the B-Mode CINE Loop only, press CINE MODE SELECTION and select B ONLY.
To review the Timeline CINE Loop only, press CINE MODE SELECTION
and select TL ONLY.
To return to linked B-Mode and Timeline CINE Loop review, press CINE MODE SELECTION
and select
B/TL
.
4-3-8-6 Moving through a CINE Loop Frame By Frame
Turn FRAME BY FRAME to move through CINE memory one frame at a time.

GE LOGIQ P5 Specifications

General

Power Supply	100-240VAC, 50/60Hz
Display	15" LCD
Doppler Modes	Color Doppler, Power Doppler
Imaging Modes	B-Mode, M-Mode
Probes	Convex, Linear, Phased Array
Applications	Abdominal, Vascular, Cardiac, OB/GYN, Small Parts, Musculoskeletal
Connectivity	DICOM, USB, Ethernet
Probe Connectors	3
Portability	Mobile
Operating Temperature	10°C to 40°C
Relative Humidity	30%
