GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
9-10 Section 9-6 - PCB
Section 9-6 PCB (cont’d)
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X R3.0.X~ R4.0.X~
400 APS Assy 5166108 LOGIQ P5 / LOGIQ A5 1 1 Yes Yes Yes Yes
401
CL1TRX Assy 5144578
LOGIQ P5 or LOGIQ A5 with
Color Option
1 1 Yes Yes Yes Yes
BL1TRX Assy 5172144 LOGIQ A5 ONLY 1 1 Yes Yes Yes Yes
402
P3RLY assy 5144579-2
LOGIQ P5 or LOGIQ A5 with 3
port option
1 1 Yes Yes Yes Yes
P2RLY assy 5144580-2 LOGIQ A5 ONLY 1 1 Yes Yes Yes Yes
403 P2RLY with dummy 5177273-2 LOGIQ P5 ONLY 1 1 Yes Yes Yes Yes
404 Backplane assy 5144581-2
Make sure to check the removal
procedure and notice of “8-2-31 -
Backplane Assy“before removing
and installation the Assy.
1 1 Yes Yes Yes Yes
405 ACWD Assy 5144582-2 1 1 Yes Yes Yes Yes
406
SYSCONPM Assy 5144584-4
LOGIQ P5 ONLY
Make sure to check the removal
procedure and notice of “8-2-33 -
SYSCON PM Assy/SYSCON CM
Assy“before removing and
installation the Assy
1 1 Yes Yes Yes Yes
SYSCONCM Assy 5177111-4
LOGIQ A5 ONLY
Make sure to check the removal
procedure and notice of 8-2-33 -
SYSCON PM Assy/SYSCON CM
Assy“before removing and
installation the Assy
1 1 Yes Yes Yes Yes
407
PM SOM Assy with 1G 5178410-2
LOGIQ P5 or LOGIQ A5 with
CPU Upgrade or Color Upgrade
Option
1 1 Yes Yes Yes Yes
CM SOM Assy with 512M 5178834-2 LOGIQ A5 ONLY 1 1 Yes Yes Yes Yes
DualCore SOM 5252327-2
PC module
Common with LP6
11 Yes
408 ASIG Assy 5144588 1 1 Yes Yes Yes Yes
409 ECG Assy 5196517 1 1 Yes Yes Yes Yes
410
L1SYSCON BASE
BOARD
5179267-4
Make sure to check the removal
procedure and notice of “8-2-33 -
SYSCON PM Assy/SYSCON CM
Assy“before removing and
installation the Assy
1 1 Yes Yes Yes Yes
411 ASIR Assy 5264181 1 1 Yes Yes Yes Yes
412 Nest Fan Assy 5144556 1 1 Yes Yes Yes Yes
Table 9-5 PCB BOARDS
To Next Page
